新格顯示工程有限公司 全戶外型字幕機規格 Synch LED Moving Sign Specification
|
Synch
LED Moving Sign Specification
|
|
Pixel Pitch (mm)
|
P20 - (20mm)
|
|
Part NO
|
P20-A050102
|
P20-A100101
|
P20-B050102
|
P20-B100101
|
P20-C050102
|
P20-C100101
|
|
Simple Describe @ 10
Chinese Words
|
R- single-row double-sided
|
R-owo-row single-side
|
RG- single-row double-sided
|
RG-owo-row single-side
|
RGB- single-row double-sided
|
RGB-owo-row single-side
|
|
Display Area WxH (cm)
|
160 x 32
|
320 x 32
|
160 x 32
|
320 x 32
|
160 x 32
|
320 x 32
|
|
Cabinet Size WxHxD
|
162 x 34 x 10
|
326 x 38 x 8
|
162 x 34 x 10
|
326 x 38 x 8
|
162 x 34 x 10
|
326 x 38 x 8
|
|
Hanging structure (cm)
|
185 x 44.2
|
326 x 56
|
185 x 44.2
|
326 x 56
|
185 x 44.2
|
326 x 56
|
|
Maximum onsumption
|
80
|
80
|
150
|
150
|
200
|
200
|
|
Resolution (Dot)
|
80 x 16 x 2
|
160 x 16
|
80 x 16 x 2
|
160 x 16
|
80 x 16 x 2
|
160 x 16
|
|
Pixel structure
|
2R
|
2R
|
2R1G
|
2R1G
|
2R1G1B
|
2R1G1B
|
|
Driving Method
|
1/4 Scan
|
Static Scan
|
|
Weight (Kg)
|
40
|
60
|
40
|
60
|
40
|
60
|
|
Cabinet Material
|
Iron With
Outdoor Powder Coating
|
|
Viewing Distance (M)
|
20 M~ 25 M
|
|
Power Required (AC)
|
AC 110V/60Hz
|
n Professional cabinet design, the use of outdoor weather resistant powder coating, the box
does not rust, without fear of strong
winds, heavy rain.
n
Built-in cooling fan, No risk
of high temperatures
n
Professional cartons to avoid
transporting and hanging
the collision damage
n
No computers, no network can update the content
n
WiFi Wireless Device
n
Hanging Structure
|
