Pixel Pitch (mm)
|
Pixel Pitch (mm)
|
P16 - (16mm)
|
|
Part NO
|
P16-A050102
|
P16-A050201
|
P16-B050102
|
P16-B050201
|
P16-C050102
|
P16-C050201
|
|
Simple Describe @ 10
Chinese Words
|
R- single-row double-sided
|
R-two-row single-side
|
RG- single-row double-sided
|
RG-two-row single-side
|
RGB- single-row double-sided
|
RGB-two-row single-side
|
|
Display Area WxH (cm)
|
128 x 25.6
|
128 x 51.2
|
128 x 25.6
|
128 x 51.2
|
128 x 25.6
|
128 x 51.2
|
|
Cabinet Size WxHxD
|
130 x 28 x 10
|
130 x 54 x 8
|
130 x 28 x 10
|
130 x 54 x 8
|
130 x 28 x 10
|
130 x 54 x 8
|
|
Hanging structure (cm)
|
150 x 382
|
150 x 638
|
150 x 382
|
150 x 638
|
150 x 382
|
150 x 638
|
|
Maximum onsumption
|
80 Watts
|
80 Watts
|
200 Watts
|
200 Watts
|
300 Watts
|
300 Watts
|
|
Resolution (Dot)
|
80 x 16 x 2
|
80 x 32
|
80 x 16 x 2
|
80 x 32
|
80 x 16 x 2
|
80 x 32
|
|
Pixel structure
|
2R
|
2R
|
2R1G
|
2R1G
|
1R1G1B
|
1R1G1B
|
|
Driving Method
|
1/4Scan
|
|
Weight (Kg)
|
30
|
40
|
30
|
40
|
30
|
40
|
|
Cabinet Material
|
Iron With Outdoor Powder Coating
|
|
Viewing Distance (M)
|
16 M~ 20 M
|
|
Power Required (AC)
|
AC 110V/60Hz
|
n Professional cabinet design, the use of outdoor weather resistant powder coating, the box
does not rust, without fear of strong winds, heavy rain.
n
Built-in cooling fan, No risk
of high temperatures
n
Professional cartons to avoid
transporting and hanging
the collision damage
n
No computers, no network can update the content
n WiFi Wireless Device
n Hanging Structure
|
