ITEM

DESCRIPTION

Pixel pitch

6.67 (mm)

 Brightness

8,500 nit

 Cabinet dimensions (WxHxD)

960x960x150 (mm)

 Cabinet dimensions (WxHxD)

37.8x37.8x5.9 (Inch)

 Panel material

Steel

 Weight

36 (kg)

 Weight

79.2 (lbs)

 Pixel configuration

 SMD 3in1 1R1G1B

 Module dimensions (WxH)

320℅320 (mm)

 Module dimensions (WxH)

12.6℅12.6(Inch)

 Pixel matrix per panel

144℅144 pixels

 Pixel density

22477 pixels/sq.m.

 Refresh rate

>1680 Hz

 Gray scale per color

4096 level

 Colors

68.7 Gillion

 Viewing angle (H/V)

120/120deg

 IP rating (Front/Rear)

IP31/IP54

 Power consumption (max/avg)

1800/600 W/sq.m.

 Input voltage (AC)

110V ~ 240V

 Operating temperature (Degree C)

﹣20 ~+ 50

 Operating humidity

10% ~ 90%

 Source compatibility (with video processor)

 AV, S-Video, VGA, DVI, HDMI, SDI, DP

Note: The above parameter is just for reference. Changes can be made according to customers' requirements.
