ITEM

DESCRIPTION

Pixel pitch

4 (mm)

 Brightness

2000 nit

 Cabinet dimensions (WxHxD)

512x512x150 (mm)

 Cabinet dimensions (WxHxD)

20.2x20.2x5.9 (Inch)

 Panel material

Steel

 Weight

8 (kg)

 Weight

22 (lbs)

 Pixel configuration

SMD 3in1 1R1G1B

 Module dimensions (WxH)

128x128 (mm)

 Module dimensions (WxH)

5.0 x 5.0(Inch)

 Pixel matrix per panel

128 x 128 pixels

 Pixel density

62,500 pixels/sq.m.

 Refresh rate

>960 Hz

 Gray scale per color

2048 level

 Colors

8.59 Gillion

 Viewing angle (H/V)

120/120deg

 IP rating (Front/Rear)

IP31/IP54

 Power consumption (max/avg)

1800/600 W/sq.m.

 Input voltage (AC)

110V ~ 240V

 Operating temperature (degree C)

﹣20 ~+ 50

 Operating humidity

10% ~ 90%

 Source compatibility (with video processor)

 AV, S-Video, VGA, DVI, HDMI, SDI, DP

Note: The above parameter is just for reference. Changes can be made according to customers' requirements.
